Aluminum is a very formable material, making it the perfect candidate to be deep drawn, stamped, or hydroformed. The deep draw metal stamping processes is a cold-forming process, meaning the material’s grain structure undergoes changes at room temperature, as the blank forms and stretches into its final shape, while simultaneously boosting its strength capabilities. As a benefit of deep draw sheet forming, the hardening of aluminum’s material properties makes it stronger and more durable as it is formed. Aluminum seamlessly formed pieces are very popular among manufacturing industries because of their strength, ductility, longevity, and great reputation.
Aluminum is a highly versatile metal that can be formed through a variety of manufacturing processes to serve a multitude of industries including food processing, aerospace, defense, medical, marine applications, and more. Why is Aluminum such a popular material choice? Because of its mechanical and physical properties:
With it’s impressive strength-to-weight ratio, it is only one-third of the weight of steel, yet is equally as strong. Because of this, aluminum is a very attractive option for aerospace, defense and other applications where high strength and low weight is key.
Though aluminum is light in weight, it can be formed into durable and long-lasting shapes. Because deep draw forming is a cold-working process, the grain structure of aluminum undergoes changes while it forms and stretches into its final shape, increasing its strength capabilities. The draw forming process allows the material to harden throughout being formed, making it stronger and more durable throughout the process. Common alloys are 6061 and 6063, both known for their excellent strength. Being such a lightweight metal with such durability makes Aluminum a top choice for a variety of industries.
Though aluminum has different properties than steel and other metals, and forms differently, it is still a great option for deep draw metal stamping. It is a great material to utilize in both low or high-volume production runs.
Aluminum is 100% recyclable, allowing it to be reprocessed and formed into new applications an infinite amount of times. It is one of the most sustainable metals available. This assists in sustainability efforts, while minimizing scrap and waste.
Aluminum behaves differently than stainless steel and other metals during the deep draw process, due to its inelastic properties. Unlike stainless steel, which can flow and redistribute its thickness under force, aluminum cannot be overstretched or excessively deformed. While aluminum can be deep drawn, it requires a more specific and controlled approach to prevent tearing or wrinkling.
The begin, the sheet metal blank must be placed properly on the press, where it is close enough to the punch to be forced into the cavity, allowing for the proper flow of metal. If the blank is placed too far or slightly off, the material will stretch, resulting in a fracture or break. The compression will result in an inward motion of the material. In other words, the metal being displaced will come out as nearly the same surface area as the initial blank. Most materials will typically resist metal flow when compressed, proving the correct amount of material and force is absolutely accurate.
A successful aluminum draw depends on maintaining the correct draw ratio: the relationship between the punch diameter and the metal blank diameter. Because aluminum strains locally with limited elongation, it lacks the stretch distribution that stainless steel offers. To ensure quality results, the press parameters must be set to balance stretching, compression, and the blank holder force appropriately. The success of the draw is also dependent on proper lubrication that responds well with aluminum. Each material requires different lubricants for different reasons, depending on their properties. With the appropriate lubrication and these parameters properly controlled, a clean and precise aluminum draw with no defects or errors can certainly be achieved.
Typical aluminum applications:Â
Aluminum is very durable, yet lighter in weight compared to other metals. Because of this, you can find aluminum at the center of many structural supports. Markets that aluminum is heavily utilized in include: aerospace, automotive, architecture, packaging, construction, railroad transportation, marine transportation, electrical appliances, medical devices/equipment, electronics, machinery, and consumer goods.
